Product model：CY300K/CY600K/CY900K
used in medicine, food, daily chemical, pesticide, health products and other industriesProducts such as sugar, coffee, seasoning, desiccant, salt, washing powder, activated carbon, medicine granules, granules, etc.
We can help you find the goods you want by phone
Machine parameters
| Model | CY300K | CY600K | CY900K | |
| Lanes number | 2-4 lanes | 3-10 lanes | 4-16 lanes | |
| Capacity | 30--50 / Max.30-50cycle/min/lane | |||
| Bag size | L 50-180mm W:25-75mm | L::50-180mm W:25-100mm | L::50-180mm W:25-110mm | |
| Film width&thickness | Max.300mm,0.07--0.1mm | Max.600mm,0.07--0.1mm | Max.900mm,0.07--0.1mm | |
| Measuring Method | 1.Vomuletric cup;2. weigher | |||
| Sealing type | 3 side sealing | 3 side sealing | 3 side sealing | |
| Cutting type | 1. Straight cutting;2. Zig zag cutting 3. Round cutting;4. Die-cut | |||
| Power supply | 1N+PE/50HZ/AC220V/380V/3.5kw | 1N+PE/50HZ/AC220V/380V/5.5kw | 1N+PE/50HZ/AC220V/380V/7.5kw | |
| Air consumption | 0.8 MPA 0.8m3/min | 0.8 MPA 0.8m3/min | 0.8 MPA 0.8m3/min | |
| Dimension | 1385*918*2005mm | 1685*1300*2005mm | 1700*1600*2500mm | |
| Weight | 400kg | 600kg | 950kg | |
Machine details
xxx
Bag forming
Bag forming 2
Horizontal and vertical sealing
Measuring cup measuring system
Measuring cup system
Bucket
Bucket 1
Machine video introduction
Effect of packaging sample bag
